Description
Gunfighter Mk.III ‘Space Combat Edition’
Adjustable dampers allow the user to adjust the friction of the stick, which results in a heavier throw with less oscillation. The all-metal gimbal supports up to two springs per axis (up to 2x #40 spring strength), which allows for a stiffer overall feel during stick movement.
Grip Options Include:
Space Combat Grip “Kosmosima” Standard
Features:
- Features:
- Left- or Right-hand versions
- Compact grip design – Perfect for tabletop joysticks
- Lockable Twist axis with contactless MaRS sensor
- Dual Action Trigger
- 3 Hat switches with center push (4-way)
- 4 Buttons
- Programmable red color LED
- Programmable RGB LED
Content:
- Grip with installed palm rest
- Palm rest for small hands
- Set of grip fasteners
–OR–
Space Combat Grip “Kosmosima” Premium
Features:
- Left- or Right-hand versions
- Compact grip design – Perfect for tabletop joysticks
- Lockable Twist axis with contactless MaRS sensor
- Dual Action Trigger
- Rapid Fire Trigger
- 3 Hat switches with center push (4-way)
- 3 buttons
- 1 analog ministick with center push (8-way)
- Programmable red color LED
- Programmable RGB LED
Content:
- Grip with installed palm rest
- Palm rest for small hands
- Set of grip fasteners
- Extra button module for C1 position
- Extra hat switch module for A1 position
- Trigger cover
- Screwdriver
- Set of screws
- Coaster (VKB-Sim Crew Kosmosima)
Specifications for all SCG variants:
- All-purpose control grip for aero-, robo-, and space simulators
- Made from industrial-grade ABS
- Compact design and low height makes it extra comfortable with desktop joysticks
- Plenty of handily positioned buttons
- 32-bit ARM controller is used for precise and speedy data computation and transmission to the joystick base
- ALPS buttons (Japan OEM) for extended longevity, and a VKB proprietary self centering twist
- User-programmable LEDs (Red and RGB)
- 2 interchangeable palm rests (total 3 palm size adjustments)
Specifications for the SCG Premium variant:
- Additional Rapid Fire trigger (shown below) allows switching between different weapon groups instantaneously
- Default analog ministick can be swapped for included hat switch (A1)
- Default hat switch with center push can be swapped for included thumb button (C1)
Included Gunfighter Mk.III Base:
Hardware:
- Built to Last
- All-metal gimbal w/ adjustable axis dampers
- Swappable cams and springs
- “Avia” cams with progressive loading (soft and hard center)
- “Space” cams with linear loading (soft and hard center)
- Cams made of hardened stainless steel alloy
- Wide stance tabletop base plate
- Blackbox w/ 32-bit ARM MCU active USB 2.0 controller
- Set of springs
- Spring installation tool
- 50 cm (1.6′) interface cable
- 180 cm (6′) USB 2.0 cable
Features:
- Works with all flight simulations
- No drivers required
- Digital Hi-resolution contactless sensors
- Save and load custom profiles
- Software tunable axes
- Upgradeable firmware via USB interface
Optional Kit:
Gunfighter Pro-L(ong) comes with a 200 mm Stick Extension
- 200 mm (8″) curved extension
- Set of #50 springs – extra strong
- Grip fastener
- Does not include Small Base Plate (offered separately)
Gunfighter Pro-S(hort) comes with a 100 mm Stick Extension
- 100 mm (4″) straight extension
- Set of #50 springs – extra strong
- Grip fastener
- Does not include Small Base Plate (offered separately)
Warranty:
- 2 Years
Instructions:
Templates:
Downloads:
- Please visit the Downloads section for configuration software, device firmware, as well as software documentation.
- VKB Gunfighter Tabletop Measurements
How to swap the A1 ministick with a HAT switch (SCG Premium):
Replacing cams and springs, adjusting the dry clutch, installing a grip on a Gunfighter base:
NOTE: The clutch dampers may be tightened at the factory to prevent them from loosening during shipping; before you connect your Gunfighter to your PC, you will need to loosen the dampers for both pitch and roll axes to achieve correct return-to-center axes movements after calibration.
